Compact Lock with high shock resistance
Ideal for installation in confined spaces
Our new shock resistant Compact Lock reliably keeps doors and flaps closed and is especially designed for installation in confined spaces. It is ready-to-install and equipped with a microswitch to detect the door position and locking process. A suitable door hook can be ordered together or seperately.
The Compact Lock features a very high shock resistance of up to 300 g in all axes and a lifetime of 100,000 switching cycles.
For safety reason, this door lock is optionally prepared with an emergency opener.
Due to its robust and compact design it is universally applicable even in limited installation spaces.
Areas of application are
- Vending machines
- Lockers
- Parcel stations
- and even more applications with small installation space
Technical data
| Technical data | |
|---|---|
| Dimensions (LxWxD) | Length 85 mm, width 55 mm and depth 18 mm |
| Operating voltage | 12 VDC & 24 VDC |
| Power consumption | Max. 36 W |
| Maximum static closing force | 500 N |
| Ambient temperature | -25 - 70° C |
| Lifetime | 20.000 switching cycles |
| Shock resistance | Up to 300 g in all axes |
| Accessories | Door hook included |
| Mounting holes | 2 holes with Ø 6,6 mm |
| Emergency opener | Optional |
